Matrix 530
Thermal laminator for OPP film up to 50 micron
DIN A2 (max. 500 mm working width)

The Matrix 530 is ideal for the print shop sector with its high quality demands. The film rolls are easy and simple to change – 1,000 m OPP film rolls can also be used. The Matrix 530 complies with the European CE standard for product safety.

Variable speed (- 10 m/min.)
and adjustable temperature setting (0 – 140° C).
Short heating times (approx. 15-20 min.)
Single side thermal lamination with 23-50 micron OPP film
1.000 m OPP film rolls usable
Paper thickness 1-sided: 135-500 g/qm, 2-sided (2 work steps) from 70 g/qm
Anti-wave bar for perfect flatness with 1-sided thermal lamination
Foot pedal
Return function
Digital display
semi-automatic paper feed with automatic alignment, print sheet feeding and overlapping
Paper separation function: perforation and automatic separation
adjustable collection tray for finished prints
Stop safety contact in protective hood
EMERGENCY OFF switch
Dust cover
incl. stable stand and storage space
Optional: Cutting arm (for individual film width trimming of the OPP film)

Technical data:
Roll core diameter: 57 + 76 mm
Working temperature: 0-140 °C
Film thickness: 23-50 micron OPP film
