for the storage of flammable liquids

Approved for the storage of flammable liquids in the workplace
according to EN 14470-1 (Type 90) and TRGS 510, Annex 3
– Tested and approved overall construction by recognized material testing institute according to EN 14470-1 (type 90) with a fire resistance of > 90 minutes
– GS-tested safety
– Insulation according to DIN 4102

– Outer body sheet steel, powder coating in RAL 7035 – light grey
– 2 hinged doors in RAL 1007 – daffodil yellow
– Inner body made of HPL coated boards – RAL 7035
– Stainless steel floor end rail – Niro rhombus
– Shelves height adjustable in increments of 64 mm

Außenmaße(BxTxH):1190x598x1935mm -753,00
Innenmaße(BxTxH):1087x430x1700mm
Weight: approx. 505 kg

Interior design, consisting of:
1 x bottom tray (collection volume 33 liters), according to WHG – Ü-sign according to StawaR
1 x perforated plate cover as 1st storage level
3 x shelf
– Door hold-open system
– In case of fire, automatic self-closing via thermomechanics
– doors when the temperature rises to < 50 °C and
– Supply and exhaust air ducts when temperature rises to 70 °C
– Ventilation connection through DN 80 pipe socket
– Operation acc. TRGS 510, Annex 3 (also approved without exhaust air!)
– Ground connection according to TRBS 2153 (avoidance of ignition sources)
– Marking according to EN 14470-1 / TRGS 510, Annex 3 / ISO 3864 / ASR A1.3
– Doors lockable via cylinder lock
